Description
Turntable
Type Belt drive turntable, fully automatic
Motor DC servo-controlled
Drive Method Belt-drive
Speeds 33-1/3 RPM, 45 RPM
Turntable Platter Aluminum
Wow and Flutter Less than 0.25% (WTD) @ 3 kHz
Signal-to-Noise Ratio >50 dB (DIN-B)
Output Level Pre-amp “PHONO”: 2.5 mV nominal at 1 kHz, 5 cm/sec
Pre-amp “LINE” 150 mV nominal at 1 kHz, 5 cm/sec
Phono Pre-Amp Gain 36 dB nominal, RIAA equalized
Power Supply Requirements 100 to 240 V, 50/60 Hz, 0.6 A Max.
Dimensions 359.5 mm (14.15″) W x 97.5 mm (3.84″) H x 373.3 mm (14.70″) D
Weight 2.6 kg (5.73 lbs)
Accessories Included Dust cover, Felt mat, Platter (with drive belt), 45 RPM adapter, RCA audio cable (approx. 1.2 m (3.9′)), AC adapter (approx. 1.5 m (4.9′))
Notes AC adapter: 12 V, 2 A
Replacement Stylus: ATN3600L
