Description
DIMENSIONS
H300 x W200 x D308mm
H11.8 x W7.9 x D12.1in
WEIGHT
Left Speaker 10.0kg (22.0lbs.)
Right Speaker 10.2kg (22.5lbs.)
WI-FI NETWORK STANDARD & FREQUENCY BAND
IEEE 802.11a/b/g/n
Dual-band 2.4GHz/ 5 GHz
DRIVER UNITS
Uni-Q driver array:
HF: 25mm (1in.) vented aluminium dome
LF/MF: 130mm (5.25in.) with magnesium and aluminium alloy
AMPLIFIER OUTPUT POWER
LF: 200W, HF: 30W
BLUETOOTH RANGE & MEMORY
10m
8 devices
RESOLUTION
Up to 24bit
Depending on source resolution
SAMPLING RATE
Up to 192kHz (USB Type B)
Up to 96kHz (TOSLINK Optical)
Depending on source resolution
MAXIMUM OUTPUT
(SPL) 106dB
WIRELESS CONNECTIVITY
Tidal and Spotify
FREQUENCY RANGE
(-6dB) Measured at 85dB/1m
40Hz – 47kHz (More bass extension)
43Hz – 47kHz (Standard)
46Hz – 47kHz (Less bass extension)
Depending on speaker settings
FREQUENCY RESPONSE
(±3dB) Measured at 85dB/1m
45Hz – 28kHz (More bass extension)
50Hz – 28kHz (Standard)
61Hz – 28kHz (Less bass extension)
Depending on speaker settings
INPUTS
2.4GHz/5GHz Dual-band Wi-Fi network
Bluetooth 4.0 with aptX® codec
USB Type B
TOSLINK Optical
RCA Analog Line Level Input
10/100 Mbps RJ45 Ethernet (For network and service)
