Oyaide AC-004 IEC Power Connector
The Oyaide AC-004 IEC Power Connector features beryllium copper contacts with platinum and palladium plating, an ARMORED dual-housing design, PBT body, and support for 8–16.5 mm cables.
The Oyaide AC-004 IEC AC Power Plug from the Armored Series is a pinnacle of precision engineering, delivering exceptional performance and durability in the realm of audio power connections. Crafted with meticulous attention to detail, this power plug exemplifies Oyaide’s commitment to high-quality components for audiophiles and audio professionals.
₹27,490
Product Details
The Oyaide AC-004 IEC Power Connector is an ARMORED Series model designed for custom audio power cables. It combines beryllium copper contacts with platinum and palladium plating, a PBT + 30% glass-fiber body, and a rigid polycarbonate housing. The dual-housing structure and flex cable clamp help secure compatible cables from 8–16.5 mm, while the connector accepts conductors up to 5.5 sq mm / 10 AWG. It is rated at 125V/15A and is PSE certified.
Technical Specifications----
- Model: Oyaide AC-004
- Series: ARMORED Series
- Connector Type: IEC power connector
- Contact Material: Beryllium copper
- Contact Finish: Buff polished
- Plating: Platinum + palladium
- Main Body: PBT + 30% glass fiber
- Housing: Polycarbonate dual housing with IP treatment
- Cable Diameter: 8–16.5 mm
- Rated Voltage/Current: 125V / 15A, PSE
Additional information
| Condition | New |
|---|
Brand
Oyaide
