Description
OVERALL
Total Pieces:1Electronics Warranty:3 yearsCabinet Warranty:5 yearsDrivers Warranty:5 yearsCarton 1:41 lbs (18.6 kg)
CENTER
Qty Included:1Availability: US InternationallyOrientation:HorizontalHeight:4″ (10.16 cm)Width:15″ (38.1 cm)Depth:3.5″ (8.89 cm)Weight:3.35 lbs (1.52 kg)Front Array Driver Complement:• (2) 2.5″ (6.35 cm) d (Round) – Midrange
• (1) 0.5″ (1.27 cm) d (Round) – TweeterTotal Frequency Response:40 Hz → 22,000 HzLower and Upper -3dB Limits:45 Hz → 20 HzMounting Type:1/4″ 20 Threaded InsertAvailable Orientations:HorizontalMounting Location:Back of SpeakerMounting Type:Keyhole HangerMounting Type:HorizontalMounting Location:Back of SpeakerPeak Power Handling:100 wattsRecommended Amplifier Power Per Channel:10 watts → 100 wattsAudio Inputs:-Speaker Inputs:(1) 5-way Binding Posts – Plastic Caps
SATELLITES
Qty Included:4Availability: USOrientation:VerticalHeight:6.5″ (16.51 cm)Width:3.75″ (9.53 cm)Depth:4.875″ (12.38 cm)Weight:1.85 lbs (0.84 kg)Driver Enclosure Type:Non-Resonant Composite w/Time-Aligned Geometry And Aperiodic Tuned PortDriver Complement:• (1) 2.5″ (6.35 cm) d (Round) – Midrange
• (1) 0.5″ (1.27 cm) d (Round) – TweeterTotal Frequency Response:40 Hz → 22 HzLower and Upper -3dB Limits:45 Hz → 20 HzMounting Type:1/4″ 20 Threaded InsertAvailable Orientations:VerticalMounting Location:Back of SpeakerMounting Type:Keyhole HangerAvailable Orientations:VerticalRecommended Amplifier Power Per Channel:10 watts → 100 wattsAudio Inputs:-Speaker Inputs:(1) 5-way Binding Posts – Plastic Caps
SUBWOOFER
Qty Included:1Availability: USOrientation:VerticalHeight:13.875″ (35.24 cm)Width:12.5″ (31.75 cm)Depth:12.5″ (31.75 cm)Weight:20.5 lbs (9.3 kg)Subwoofer Array Driver Enclosure Type:Downward Firing Vented PortSubwoofer Array Driver Complement:• (1) 8″ (20.32 cm) d (Round) – SubwooferTotal Frequency Response:40 Hz → 22 HzLower and Upper -3dB Limits:45 Hz → 22 HzAudio Inputs:-Speaker Inputs:(1) 5-way Binding Posts – Plastic Caps
