Lehmannaudio Drachenfels USB Headphone Amplifier with ESS Sabre DAC
The Lehmannaudio Drachenfels USB Headphone Amplifier combines refined analogue amplification with a high-resolution USB DAC. It supports up to 32-bit/384kHz audio, uses an ESS Sabre K2M chipset, and offers automatic digital-to-analogue switching for simple, high-quality listening.
Drachenfels USB preamp and headphone amp redefines how portable and computer-based music can sound. By bypassing the often limited internal audio circuitry of computers and phones, it delivers the full sonic potential of your digital files.
From high-resolution streaming services to locally stored tracks, the Drachenfels USB translates every detail into a balanced, natural soundstage, making it ideal for both casual listening and critical music sessions.
₹164,900
Product Details
The Lehmannaudio Drachenfels USB Headphone Amplifier brings high-resolution computer audio to a refined analogue headphone amp. Its USB-B DAC supports up to 32-bit/384kHz audio and uses an ESS Sabre K2M chipset for detailed playback.
Moreover, the unit automatically switches to analogue input when no digital signal is present. With 110 mW at 330 Ω, 180 mW at 33 Ω, two headphone outputs, and a pre-out, the Drachenfels USB works well for both personal listening and compact hi-fi systems.
Technical Specifications:
- Type: USB DAC, headphone amplifier and preamplifier
- Digital Input: 1 × USB-B
- DAC Chipset: ESS Sabre K2M
- Maximum Sampling Rate: Up to 384 kHz
- Maximum Resolution: Up to 32-bit
- Supported Formats: PCM, DoP 128, FLAC, MP3 and WAV
- Maximum DAC Output Voltage: 1.8 V RMS
- Maximum Gain: 12 dB
- Headphone Output Power: 110 mW at 330 Ω; 180 mW at 33 Ω
- Dimensions / Weight: 160 × 120 × 43 mm; 0.5 kg
Additional information
| Condition | New |
|---|---|
| Finish | Black, Silver |
