Marantz MODEL 30 Integrated Amplifier – 100W Discrete HDAM Hi-Fi Amp
The Marantz MODEL 30 Integrated Amplifier provides 100W per channel performance with true, discrete HDAM-SA3 audio sound. This Marantz MODEL 30 HDAM amplifier includes an MM/MC phono input, toroidal transformer, and high-purity copper speaker binding posts. Sound Master Tuned for accuracy in music reproduction.
Technical Features:
-
- Custom-built preamplifier with Marantz HDAM technology
- Tuned with passion by the Marantz Sound Master
- Output: 100W + 100W (8ohm), 200W + 200W (4ohm)
- Fully-discrete design for signal purity
- Custom HDAM®-SA3 circuitry for clean, optimal dynamics
- Separate amp and preamp power supplies reduce interference
- Toroidal transformer dedicated to preamp for clarity and power
- Current feedback preamp design with its wide-range circuitry
- MM/MC Phono input with its Premium Phono EQ circuit
- Brass machined input terminals for CD and Phono
- Marantz original high-quality/high-purity copper speaker terminals
- Linear volume control with new electric volume system
- Amplifier design inherited from our flagship models
₹425,900
Product Details
Experience original audio quality with the Marantz MODEL 30 Integrated Amplifier. In addition, the independent pre-amplifier and power amplifier sections provide excellent transparency, as does the internal MM/MC phono section that supports moving magnet and moving coil cartridges.
Marantz MODEL 30 HDAM amplifier
This beautifully engineered amplifier provides 100 watts per channel using HDAM-SA3 technology. Plus, high-purity copper speaker terminals and a toroidal transformer add definition and dynamics to each piece of music. This is an amplifier built to last for generations, and it complements the SACD 30n perfectly. Available in Black or Silver-Gold.
- TECHNICAL SPECIFICATIONS:
Features: |
|
| Aluminium extrusion heat sink | o (Seperate) |
| Balance / Bass / Treble / Loudness | o / o / o / - |
| Channels | 2 |
| Current Feedback Topology | o |
| Customised Components | o |
| Digital in: USB-B / optical / coaxial / USB-A | - / - / - / - |
| HDAM version | SA3, SA2 |
| High Grade Audio Components | o |
| Phono EQ: Standard / Marantz Musical / Marantz Musical Premium | - / - / o |
| Power Transformer: Toroidal / El | SMPS |
| Symmetric PCB Layout | o |
| General | |
| Auto power off | o |
| Carton Maximum Dimensions (W x D x H) in mm | 534 x 522 x 255 |
| Carton Weight (inc. product) in kg | 17.6 |
| Detachable Power Cable | o |
| Maximum Dimensions (W x D x H) in mm | 443 x 431 x 130 |
| Metal Front Panel | o |
| Power Consumption in W | 130 |
| Remote Control | RC002PMND |
| Standby Consumption in W | 0.2 |
| System Remote Function | o |
| Weight in kg | 14.8 |
| Inputs/Outputs | |
| Audio Inputs | 6 |
| Audio Outputs | 1 |
| Balanced In / Out | - / - |
| D-Bus | o |
| Digital in: USB-B / optical / coaxial / USB-A | - / - / - / - |
| Floating Control Bus (3.5 mm mono jack x 2) | - |
| Gold Plated Cinch | o |
| HDMI: inputs / outputs | - |
| Headphone Gain Control (low / mid / high) | - |
| Headphone Out | o |
| Number of terminals | 2 |
| Phono Input: MM / MC | o / o |
| Power Amp Direct IN | o |
| Pre-out / Main-in | o / - |
| Speaker A / B | - |
| Speaker Terminals | Marantz SPKT-100+ |
| Damping Factor | 500 |
| Frequency Response | 5 Hz - 50kHz |
| Input Sensitivity: Balanced High level | - |
| Input Sensitivity: High level | 220 mV / 13 kohm |
| Input Sensitivity: MC | 250 |
| Input Sensitivity: MM | 2.3 mV / 39 kohm |
| Input Sensitivity: Power Amp Direct IN | - |
| Power Output (8 / 4 Ohm RMS) | 100 W / 200 W |
| Signal to Noise Ratio: High level | 107 dB(2V input/Rated output) |
| Signal to Noise Ratio: MM / MC | 88 / 75 dB |
| Signal to Noise Ratio: Power Amp Direct IN | - |
| Total Harmonic Distortion | 0.005% |
Additional information
| Condition | New |
|---|---|
| Finish | Black, Silver |
