Q Acoustics Q SUB80 Active Subwoofer

The Q Acoustics Q SUB80 Active Subwoofer adds powerful, controlled bass to music and home cinema systems. Its 203 mm driver, DSP processing and 400 W peak amplifier deliver deep low-frequency impact, while the sealed cabinet supports flexible placement.



OVERVIEW:

  • Q SUB80 has exceptional bass power to cabinet size ratio.
  • Digital Signal Processing (DSP) allows easy system and room integration with optimise settings for class-leading, distortion-free performance.
  • Clever, dual phase and delay controls allow the fine-tuning of the signal alignments for flexible room placement.
  • DSP identifies the input signal and automatically adjusts system gain, enhancing performance regardless of the connected source.
  • A low pass filter with frequency adjustment ensures seamlessly integration with any partnering speaker system.
  • A custom-designed amplifier module features four digital power amplifier stages that improves efficiency by dissipating less heat, enhances speaker control, and reduces output impedance.

₹95,900

Product Details

The Q Acoustics Q SUB80 Active Subwoofer delivers deep, controlled bass for music, movies and home cinema. Its 203 mm driver works with a 200 W continuous, 400 W peak amplifier and DSP for precise system integration.

Dual phase and delay controls help optimise placement, while automatic source detection adjusts system gain for different inputs. Its sealed infinite-baffle cabinet also supports placement near walls and furniture. Choose Satin Black or Satin White to complement your audio system.



Technical Specifications:

  1. Subwoofer Type: Active subwoofer
  2. Enclosure Type: Infinite baffle / sealed cabinet
  3. Bass Driver: 203 mm (8 in)
  4. Effective Volume: 13.9 litres
  5. Maximum SPL: 107 dB @ 1 m
  6. Frequency Response: 36 Hz–250 Hz (-6 dB)
  7. Low-Pass Crossover Range: 50 Hz–250 Hz
  8. Peak Amplifier Power: 400 W
  9. Continuous Amplifier Power: 200 W
  10. THD at Rated Power: 0.09%
  11. Input Sensitivity: 300 mV RMS at maximum gain
  12. Maximum Input Level: 2.1 V RMS
  13. Input Impedance: 20 kΩ
  14. Noise Floor: 50 μV A-weighted
  15. Dimensions: 315 × 315 × 347 mm (H × W × D)
  16. Weight: 15 kg
  17. Available Finishes: Satin Black and Satin White

Additional information

Condition

New

Finish

Satin Black, Satin White

Brand

Q Acoustics
